Actus-G View Camera for Hasselblad XCD
Couldn't load pickup availability
Actus-XCD
Includes:
- Cambo ACTUS-XCD View Camera Body
- AC-210, 125mm Standard bellows
- AC-315, 155mm Standard Monorail
- AC-793, Actus-G Interchangeable Hasselblad XCD Camera Mount
The Cambo ACTUS-XCD is the Actus mini view camera optimized for use with the mirrorless Hasselblad X1D and X2D.
It comes with a standard bellows and an adapter to accept the Hasselblad camera body.
A view camera adds versatility to the photographer's tool kit. Expand your creativity and get professional results in one shot. Using selective focus or optimization of the focus plane are great tools in i.e. food and product photography. Architectural photographers will appreciate the rise/fall and shift movements.
Mirrorless camera bodies can be used as digital back. The Actus adds view camera movements - rise/fall, shift, tilt and swing - to any suitable lens.
Size matters. The Cambo ACTUS has been designed to provide maximum functionality in a small and light form factor.
The basic configuration of a Cambo ACTUS-XCD consists of:
- a monorail
- front assembly without lensplate
- a rear frame with XCD camera bayonet
- standard bellows
Technical details
| Dimensions LxWxH | 152 x 115 x 171 mm |
| Weight | 1150 grams |
| Front Swing | 360 degrees |
| Front Tilt | 19 degrees (+10/-9) |
| Rear Shift Vertical | 27 mm (12/15) |
| Rear Shift Horizontal | 40 mm (20/20) |
| Focus Travel | up to 134mm (-GFX-sensor) |
| Available colors | Black anodised |
Note: Cambo ACTUS shown with optional lenses and optional camera body. Hasselblad X1D and X2D cameras don't have in-body shutters. For use with a view camera the photographer will have to rely on the Electronic (rolling) Shutter.
Lensplate options
- Lensplate options
- Cambo ACTAR lens series
- Copal 0 and 1 (#3 on request)
- Hasselblad C Bayonet
- M39 Leica thread
- Mamiya 645 ProTL bayonet
- Mamiya RZ/RB bayonet
- Pentax 645 bayonet (for mirror less bodies only)
Interchangeable Camera Mount
The Cambo Actus-XCD comes standard with a XCD interchangeable camera mount, enabling an effortless swap between various camera systems. Just add the required camera mount.
